Arial Pro IP44

Arial Pro 20W IP44 LED CCT Downlight with 1-10V Dimming

Code
10961
Technical Specification
Volts (V)
220/240
Watts (W)
20
Colour Temp (K)
3000/4000/6000
Lumens (lm)
2612 (3000K) / 2885 (4000K) / 2585 (6000K)
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings. With a 7 year guarantee across both the IP44 & IP65 range, the Arial Pro can be installed in a variety of applications with the confidence of knowing this product will stand the test of time.
Download Specification
Full Specification
Downloads
Name
Arial Pro 20W IP44 LED CCT Downlight with 1-10V Dimming
Volts (V)
220/240
Watts (W)
20
Colour Temp (K)
3000/4000/6000
Lumens (lm)
2612 (3000K) / 2885 (4000K) / 2585 (6000K)
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
500mA
Energy Consumption (kWh/1000h)
20
IP Rating
IP44
Downlight Cut Out (mm)
200-210
Commodity Code
9405423100
EAN
5013588109619
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00894
Height (mm)
117
Diameter (mm)
240
Outer Box Height (mm)
475
Outer Box Width (mm)
515
Outer Box Depth (mm)
515
Single Carton Weight (KG)
0.75
Single Carton Height (mm)
143
Single Carton Width (mm)
250
Single Carton Depth (mm)
250
Outer Box Weight (kg)
10.5
Outer Box Volume
0.12598
Outer Box Qty
12
Individual Product Weight (kg)
0.56
Lumens per Watt (lm/W)
129-144
Equivalent Watts (W)
100
Electric Class
2
Power Factor
>0.9
Driver Integral?
No
Dimming Option
1-10V
Product Category
LED Luminaires - Plastic
Outer Carton Barcode
1096100000012
Product Application
LED Downlight
