Firestay Duo V2 Downlights

Firestay Duo 4/6W LED CCT Wattage Switchable Downlight - Tool Free Lever Connector - Bezels Sold Separately

Code
11370V2
Next Delivery
20/01/2026 - 16,390 items
Technical Specification
Volts (V)
220/240
The Firestay Duo LED CCT is a High Output Downlight ideal for high ceilings or any project requiring high intensity light.
Download Specification
Full Specification
Downloads
Name
Firestay Duo 4/6W LED CCT Wattage Switchable Downlight - Tool Free Lever Connector - Bezels Sold Separately
Commodity Code
9405423100
EAN
5013588900025
Volts (V)
220/240
Life Hours
50000
Beam Angle
60°
Guarantee
8 Years
Frequency (Hz)
50/60
IP Rating
IP65
Diameter (mm)
90
Individual Product Weight (kg)
0.195
Inner Box Weight (kg)
2.7
Inner Box Height (mm)
490
Inner Box Width (mm)
200
Inner Box Depth (mm)
90
Outer Box Weight (kg)
5.6
Outer Box Height (mm)
507
Outer Box Width (mm)
224
Outer Box Depth (mm)
218
Inner Box Qty
10
Outer Box Qty
20
Outer Box Volume
0.02476
Inner Box Volume
0.00882
CRI (Ra)
85
Height (mm)
34
Lumens per Watt (lm/W)
136-164
Energy Consumption (kWh/1000h)
6
Dimming Option
Leading & Trailing Edge (Trailing Edge Recommended)
Primary Material
Die-Cast Aluminium
Operating Temperature
-5°C - + 35°C
Surge Protection
2kV
Wattage (W)
4/6
Colour Temperature (K)
2700/3000/4000/6000
Candelas
380-580
IK Rating
IK07
Minimum Order Quantity
1
Single Box Weight (kg)
0.235
Single box Height (mm)
80
Single box Width (mm)
97
Single Box Depth (mm)
95
Single Box Volume
0.0007372
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Downlights
EDATA Product Range
Firestay Duo
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
4W = 620 (2700K) / 630 (3000K) / 655 (4000K) / 652 (6000K) - 6W = 816 (2700K) / 853 (3000K) / 908 (4000K) / 907 (6000K)
Dimmable
Yes
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
No
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
Domestic External Lighting
No
Retrofit Solutions
No
Apex
No
Cityline
No
Alto Street Light
No
Apex Dura CCT
No
Apex Mentor
No
Apex Ultra CCT
No
Arial Linus
No
Skyline Virtus CCT
No
Catalogue Page

Instructions

Photometric Data

Product Image

Case Study Image
