Skyline Omni Wattage Switchable - Loop In Loop Out

Skyline Omni 200/250/300W Wattage Switchable LED Floodlight - Symmetric - Loop In Loop Out - 3CCT

Code
72045
Technical Specification
Volts (V)
220/240
The Skyline Omni is a CCT Floodlight with Wattage Switchability in higher wattage models, featuring a compact design, adjustable bracket and tempered glass cover.
Download Specification
Full Specification
Downloads
Name
Skyline Omni 200/250/300W Wattage Switchable LED Floodlight - Symmetric - Loop In Loop Out - 3CCT
Commodity Code
9405423990
EAN
5063695003416
Volts (V)
220/240
Energy Consumption (kWh/1000h)
300
Lumens per Watt (lm/W)
157 at 4000K
CRI (Ra)
80
Life Hours
50000
Guarantee
7 Years
Frequency (Hz)
50/60
Switching Cycles
25000
LED Drive Current
1470mA at 230V
IP Rating
IP66
Depth (mm)
77
Height (mm)
515
Width (mm)
440
Windage
0.133m²
Flex
1.5m
Electric Class
Class I
Power Factor
0.9
Operating Temperature
-40℃ - +45℃
Individual Product Weight (kg)
9.6
Wattage (W)
200/250/300
Colour Temperature (K)
3000/4000/5000
IK Rating
IK08
Minimum Order Quantity
1
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
UOM For Battery Weight
KG
Lumen output (lm)
200W = 31400 at 4000K / 250W = 39250 at 4000K / 300W = 47100 at 4000K
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Corrosion Rating
300 hour salt spray - C3 Corrosion Rating
