Skyline Omni Wattage Switchable - Photocell Switch

Skyline Omni 50/80/100W Wattage Switchable LED Floodlight with Photocell Switch - Asymmetric - 3CCT

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
72049
Technical Specification
Volts (V)
220/240
The Skyline Omni is a CCT Floodlight with Wattage Switchability in higher wattage models, featuring a compact design, adjustable bracket and tempered glass cover.
Download Specification
Full Specification
Downloads
Name
Skyline Omni 50/80/100W Wattage Switchable LED Floodlight with Photocell Switch - Asymmetric - 3CCT
Commodity Code
9405423990
EAN
5063695005045
Volts (V)
220/240
Energy Consumption (kWh/1000h)
100
Lumens per Watt (lm/W)
147 at 4000K
CRI (Ra)
80
Life Hours
50000
Guarantee
7 Years
Frequency (Hz)
50/60
Switching Cycles
25000
LED Drive Current
490mA at 230V
IP Rating
IP65
Depth (mm)
65
Height (mm)
405
Width (mm)
293
Windage
0.082m²
Flex
1.5m
Electric Class
Class I
Power Factor
0.9
Operating Temperature
-40℃ - +45℃
Individual Product Weight (kg)
3.325
Outer Box Qty
2
Outer Box Weight (kg)
7.43
Outer Box Height (mm)
327
Outer Box Width (mm)
151
Outer Box Depth (mm)
459
Outer Box Volume
0.022664043
Wattage (W)
50/80/100
Colour Temperature (K)
3000/4000/5000
IK Rating
IK08
Minimum Order Quantity
1
Single Box Weight (kg)
3.505
Single box Height (mm)
309
Single box Width (mm)
65
Single Box Depth (mm)
399
Single Box Volume
0.008013915
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
UOM For Battery Weight
KG
Lumen output (lm)
50W = 7350 at 4000K / 80W = 11760 at 4000K / 100W = 14700 at 4000K
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Corrosion Rating
300 hour salt spray - C3 Corrosion Rating
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
No
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
EDATA Product Family
LED Floodlights
EDATA Product Range
Skyline Omni
EDATA Quantity Interval
1
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
Domestic External Lighting
No
Retrofit Solutions
No
Apex
No
Cityline
No
Alto Street Light
No
Apex Dura CCT
No
Apex Mentor
No
Apex Ultra CCT
No
Arial Linus
No
Skyline Virtus CCT
No
Catalogue Page

Instructions

Product Image

Case Study Image
