Powertron Medium Asymmetric Beam (MAB)

Skyline Powertron 600W LED Asymmetric (MAB) Floodlight - 4200K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11829
Technical Specification
Colour Temp (K)
4200
Lumens (lm)
92589
Volts (V)
200-400 (Single/Cross Phase)
Watts (W)
600
Please contact our Lighting Design Team through lightingdesign@belllighting.co.uk for LDT files which include shields and other optional attachments.
Download Specification
Full Specification
Downloads
Name
Skyline Powertron 600W LED Asymmetric (MAB) Floodlight - 4200K
Commodity Code
9405423990
EAN
5013588118291
Country Of Origin
CN
Colour Temp (K)
4200
Lumens (lm)
92589
Volts (V)
200-400 (Single/Cross Phase)
Watts (W)
600
Life Hours
100000
CRI (Ra)
70
Guarantee
10 Years
Switching Cycles
200000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
600
IP Rating
IP66
Height (mm)
474
Width (mm)
605
Depth (mm)
172
UNSPSC Code
39111626
Individual Product Weight (kg)
Including Driver - 13.2 / Remote Driver - 8.9 (Weights Do Not Include Visor)
Impact Protection
IK8
Equivalent Watts (W)
1000
Lumens per Watt (lm/W)
154
Windage
0.07m² at 0° / 0.1m² at 15° / 0.14m² at 30°
Product Category
LED Luminaires - Not Plastic
Product Application
Sports Lighting
LED Chip
OSRAM 3737
Power Factor
>0.9
Operating Temperature
-30°C to +35°C
Lumens Maintenance Ratio
L80 B10
Surge Protection
10KV
Driver Integral?
No
Dimming Option
Dali
Catalogue Page

Instructions

Photometric Data

Product Image
