Powertron Narrow Asymmetric Beam (NAB)

Skyline Powertron 1800W LED Asymmetric (NAB) Floodlight - 4200K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11332
Technical Specification
Volts (V)
200-400 (Single/Cross Phase)
Watts (W)
1800
Colour Temp (K)
4200
Lumens (lm)
283330
The Skyline Powertron Asymmetric LED Floodlight is the highest lumen output floodlight ever produced by BELL. The black powder coated die cast aluminium construction gives an ultra-modern aesthetic combined with a staggering 260,000 lumen output (1800W). The rugged, robust construction of the Powertron makes this fitting ideal for external sports facilities open to the elements.
Download Specification
Description
Full Specification
Downloads

The Skyline Powertron Asymmetric LED Floodlight is the highest lumen output floodlight ever produced by BELL. The black powder coated die cast aluminium construction gives an ultra-modern aesthetic combined with a staggering 260,000 lumen output (1800W). The rugged, robust construction of the Powertron makes this fitting ideal for external sports facilities open to the elements.

  • Up to 146 Lm/W
  • Fully adjustable angled mounting bracket
  • Suitable for multiple row columns installation
  • Angle markings on bracket for easy alignment
  • Full cut-off horizontal asymmetric floodlight
  • Low weight & windage
  • Optional ULR Shields available for 0° upward light, glare and obstructive light reduction
  • Remote driver box, can be mounted on ground level for easy maintenance
Name
Skyline Powertron 1800W LED Asymmetric (NAB) Floodlight - 4200K
Volts (V)
200-400 (Single/Cross Phase)
Watts (W)
1800
Colour Temp (K)
4200
Lumens (lm)
283330
Life Hours
100000
CRI (Ra)
70
Guarantee
10 Years
Switching Cycles
200000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
1800
IP Rating
IP66
Height (mm)
1100
Width (mm)
605
Depth (mm)
332
Commodity Code
9405423990
EAN
5013588113326
Country Of Origin
CN
UNSPSC Code
39111626
Individual Product Weight (kg)
Including Driver - 36.3 / Remote Driver - 30.4 (Weights Do Not Include Visor)
Impact Protection
IK8
Outer Box Qty
1
Lumens per Watt (lm/W)
158
Windage
0.11m² at 0° / 0.26m² at 15° / 0.39m² at 30°
Product Category
LED Luminaires - Not Plastic
Product Application
Sports Lighting
LED Chip
OSRAM 3737
Power Factor
>0.9
Operating Temperature
-30°C to +35°C
Lumens Maintenance Ratio
80
Surge Protection
10000 Volts
Driver Integral?
No
Dimming Option
Dali
Catalogue Page

Instructions

Photometric Data

Product Image
