Skyline Virtus Symmetric

Skyline Virtus 50/75/100W Wattage Switchable Symmetric Floodlight - 4000K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11486
Technical Specification
Volts (V)
110/240
Watts (W)
50/75/100
Colour Temp (K)
4000
Lumens (lm)
7493 (50W) / 11201 (75W) / 15137 (100W)
Designed and engineered in the UK specifically to meet the requirements for sports lighting and to reduce light pollution levels. The Skyline Virtus is a high specification floodlight, wattage switchable as standard with a 50,000 hour lifespan, 7 year warranty and 2 year on site warranty.
Download Specification
Full Specification
Downloads
Name
Skyline Virtus 50/75/100W Wattage Switchable Symmetric Floodlight - 4000K
Volts (V)
110/240
Watts (W)
50/75/100
Colour Temp (K)
4000
Lumens (lm)
7493 (50W) / 11201 (75W) / 15137 (100W)
Life Hours
50000
CRI (Ra)
80
Guarantee
7 Years
Switching Cycles
100000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
100
IP Rating
IP66
Height (mm)
353
Width (mm)
287
Depth (mm)
65
Country Of Origin
CN
Individual Product Weight (kg)
2.8
Commodity Code
9405423990
EAN
5013588114866
UNSPSC Code
39111626
Impact Protection
IK8
Equivalent Watts (W)
250
Lumens per Watt (lm/W)
149-151
LED Drive Current
130mA
Flex
1.5m
Power Factor
>0.9
Product Category
LED Luminaires - Not Plastic
Product Application
Sports Lighting
LED Chip
Nichia GRT-V1
Surge Protection
6KV
Operating Temperature
-30°C to +35°C
Lumens Maintenance Ratio
80
Windage
0.067m²
Single Carton Weight (KG)
3.5
Single Carton Height (mm)
375
Single Carton Width (mm)
320
Single Carton Depth (mm)
90
Individual Volume
0.0108
