Mentor Wattage Switchable & CCT

Mentor 20/27/33/38W LED 4ft CCT Batten

Code
10285V2
Technical Specification
Volts (V)
220/240
Watts (W)
20/27/33/38
Colour Temp (K)
3000/4000/6000
Lumens (lm)
20W = 2667 (3000K) / 2835 (4000K) / 2857 (6000K) - 27W = 3600 (3000K) / 3827 (4000K) / 3857 (6000K) - 33W = 4168 (3000K) / 4430 (4000K) / 4464 (6000K) - 38W = 4799 (3000K) / 5101 (4000K) / 5140 (6000K)
The Mentor Wattage Switchable LED Integrated CCT Batten is colour switchable, with a choice of 3000K, 4000K, or 6000K, depending on the application. This is a 36-in-1 fitting with plug-in emergency packs, microwave and PIR sensors, and a Dali Dimming option available.
Download Specification
Full Specification
Downloads
Name
Mentor 20/27/33/38W LED 4ft CCT Batten
Volts (V)
220/240
Watts (W)
20/27/33/38
Colour Temp (K)
3000/4000/6000
Lumens (lm)
20W = 2667 (3000K) / 2835 (4000K) / 2857 (6000K) - 27W = 3600 (3000K) / 3827 (4000K) / 3857 (6000K) - 33W = 4168 (3000K) / 4430 (4000K) / 4464 (6000K) - 38W = 4799 (3000K) / 5101 (4000K) / 5140 (6000K)
Candelas (cd)
874-1639
Life Hours
50000
Beam Angle
115°
CRI (Ra)
80
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
960mA
Energy Consumption (kWh/1000h)
20/27/33/38
IP Rating
IP40
Height (mm)
97
Length (mm)
1205
Commodity Code
9405423100
EAN
5013588000664
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
3.52
Single Carton Weight (KG)
3.82
Single Carton Height (mm)
105
Single Carton Width (mm)
205
Single Carton Depth (mm)
1210
Individual Volume
0.02604525
Outer Box Weight (kg)
7.6
Outer Box Height (mm)
230
Outer Box Width (mm)
220
Outer Box Depth (mm)
1225
Outer Box Qty
2
Outer Box Volume
0.061985
Guarantee
7 Years
Impact Protection
IK8
Lumens per Watt (lm/W)
133-143
Depth (mm)
200
Product Category
LED Luminaires - Plastic
Product Application
Schools / Colleges / Offices
Outer Carton Barcode
10285V2000002
