Mentor Wattage Switchable & CCT

Mentor 25/34/40/48W LED 5ft CCT Batten

Code
10286V2
Technical Specification
Volts (V)
220/240
Watts (W)
25/34/40/48
Colour Temp (K)
3000/4000/6000
Lumens (lm)
3470-6480
Energy Rating
E
The Mentor Wattage Switchable LED Integrated CCT Batten is colour switchable, with a choice of 3000K, 4000K, or 6000K, depending on the application. This is a 36-in-1 fitting with plug-in emergency packs, microwave and PIR sensors, and a Dali Dimming option available.
Download Specification
Full Specification
Downloads
Name
Mentor 25/34/40/48W LED 5ft CCT Batten
Volts (V)
220/240
Watts (W)
25/34/40/48
Colour Temp (K)
3000/4000/6000
Lumens (lm)
3470-6480
Candelas (cd)
1099-1982
Life Hours
50000
Beam Angle
115°
CRI (Ra)
80
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
1080mA
Energy Consumption (kWh/1000h)
25/34/40/48
IP Rating
IP40
Height (mm)
97
Width (mm)
200
Length (mm)
1505
Commodity Code
9405423100
EAN
5013588000671
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
4.18
Single Carton Weight (KG)
4.58
Single Carton Height (mm)
105
Single Carton Width (mm)
205
Single Carton Depth (mm)
1510
Individual Volume
0.03250275
Outer Box Weight (kg)
9.26
Outer Box Height (mm)
230
Outer Box Width (mm)
220
Outer Box Depth (mm)
1525
Inner Box Qty
1
Outer Box Qty
2
Outer Box Volume
0.077165
Energy Rating
E
Guarantee
7 Years
Impact Protection
IK8
Lumens per Watt (lm/W)
135-139
