Aqua Endure Emergency

Aqua Endure 18-36W LED CCT Power Switch Standard Anti-Ligature Bulkhead in Self-Test Emergency with Microwave Corridor Dim

Code
70038
Technical Specification
Volts (V)
220/240
Watts (W)
18-36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
4320
Energy Rating
D
Download Specification
Full Specification
Downloads
Name
Aqua Endure 18-36W LED CCT Power Switch Standard Anti-Ligature Bulkhead in Self-Test Emergency with Microwave Corridor Dim
Volts (V)
220/240
Watts (W)
18-36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
4320
Equivalent Watts (W)
67
Life Hours
100000
Beam Angle
117°
Energy Rating
D
CRI (Ra)
80
Switching Cycles
50000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
36
IP Rating
IP66
Height (mm)
110
Diameter (mm)
400
Commodity Code
9405423990
EAN
5013588700380
Country Of Origin
CN
Individual Product Weight (kg)
3.77
Single Carton Weight (KG)
4.94
Single Carton Height (mm)
165
Single Carton Width (mm)
447
Single Carton Depth (mm)
447
Individual Volume
0.032968485
Outer Box Weight (kg)
11.04
Outer Box Height (mm)
470
Outer Box Width (mm)
470
Outer Box Depth (mm)
365
Inner Box Qty
1
Outer Box Qty
2
Outer Box Volume
0.0806285
UNSPSC Code
39111612
Guarantee
10 Years
Impact Protection
IK20
Lumens per Watt (lm/W)
120
Product Category
LED Luminaires - Not Plastic
Instructions

Photometric Data
