Aqua Endure Standard

Aqua Endure 18-36W LED CCT Power Switch Anti-Ligature Bulkhead

Code
70035
Technical Specification
Volts (V)
220/240
The Aqua Endure is an anti-ligature and anti-vandal bulkhead, perfect for use in areas where a fitting's durability is paramount.
Download Specification
Full Specification
Downloads
Name
Aqua Endure 18-36W LED CCT Power Switch Anti-Ligature Bulkhead
Volts (V)
220/240
Life Hours
100000
Beam Angle
117°
CRI (Ra)
80
Switching Cycles
50000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
36
IP Rating
IP66
Height (mm)
110
Diameter (mm)
400
Commodity Code
9405423990
EAN
5013588700359
Individual Product Weight (kg)
3.62
Outer Box Weight (kg)
10.74
Outer Box Height (mm)
470
Outer Box Width (mm)
470
Outer Box Depth (mm)
365
Outer Box Qty
2
Outer Box Volume
0.0806285
Guarantee
10 Years
Lumens per Watt (lm/W)
158-173
Wattage (W)
18-36
Equivalent Wattage (W)
67
Colour Temperature (K)
3000/4000/6000
IK Rating
IK20
Minimum Order Quantity
1
Single Box Weight (kg)
4.79
Single box Height (mm)
165
Single box Width (mm)
447
Single Box Depth (mm)
447
Single Box Volume
0.032968485
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Bulkheads
EDATA Product Range
Aqua Endure
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
18W = 2847 (3000K) / 3027 (4000K) / 3111 (6000K) - 23W = 3637 (3000K) / 3868 (4000K) / 3975 (6000K) - 28W = 4428 (3000K) / 4708 (4000K) / 4839 (6000K) - 36W = 5680 (3000K) / 6102 (4000K) / 6260 (6000K)
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
