DECO Slim Emergency

Deco Slim 25W LED Bulkhead in Emergency with Microwave Sensor - 4000K

Code
06751
Stock
Discontinued
This product has been discontinued. Please see our alternative listed below:
06829 - 25W Deco Slim LED Bulkhead - CCT, Sensor Emergency View product
Technical Specification
Volts (V)
220/240
The colour selectable Deco Slim LED Bulkhead is one of the most decorative, aesthetically pleasing bulkheads in the BELL range. Supplied with white bezel as standard with the option to add a variety of decorative bezels.
Quantity
Download Specification
Full Specification
Downloads
Name
Deco Slim 25W LED Bulkhead in Emergency with Microwave Sensor - 4000K
Volts (V)
220/240
Candelas
830
Life Hours
50000
Beam Angle
111°
CRI (Ra)
85
Guarantee
5 Years
LED Drive Current
140mA
Energy Consumption (kWh/1000h)
25
Commodity Code
9405423100
EAN
5013588067513
Outer Box Qty
10
Diameter (mm)
300
Outer Box Height (mm)
325
Outer Box Width (mm)
570
Outer Box Depth (mm)
325
Individual Product Weight (kg)
0.901
Outer Box Weight (kg)
11
Outer Box Volume
0.06021
Depth (mm)
48
Frequency (Hz)
50/60
Lumens per Watt (lm/W)
86
Switching Cycles
20000
Power Factor
0.96
Flicker (SVM)
1.4
Wattage (W)
25
Equivalent Wattage (W)
55
Colour Temperature (K)
4000
IK Rating
IK08
Minimum Order Quantity
1
Single Box Weight (kg)
1.058
Single box Height (mm)
52
Single box Width (mm)
305
Single Box Depth (mm)
305
Single Box Volume
0.00484
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Bulkheads
EDATA Product Range
Decoslim
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
2150
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Catalogue Page
