Arial Multi Plus Emergency - Casambi

Arial Plus Multi Backlit 50W LED UGR<19 1200x600 White Panel in Emergency - Casambi Dimming Enabled - 4000K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
82174
Technical Specification
Volts (V)
220/240
The Arial Plus Multi is our leading wattage switchable panel. The Arial Plus Multi can be installed in areas where TPa rated lighting products are essential, such as emergency exit routes including stairways and corridors.
Download Specification
Full Specification
Name
Arial Plus Multi Backlit 50W LED UGR<19 1200x600 White Panel in Emergency - Casambi Dimming Enabled - 4000K
EAN
5063695002167
Volts (V)
220/240
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
50
IP Rating
IP40
Height (mm)
1195
Width (mm)
595
Depth (mm)
25
Lumens per Watt (lm/W)
115
Unified Glare Rating
<19
Primary Material
Steel
Operating Temperature
0°C-35°C
Commodity Code
9405423990
Individual Product Weight (kg)
4.787
Outer Box Height (mm)
1295
Outer Box Width (mm)
640
Outer Box Depth (mm)
170
Outer Box Qty
5
Outer Box Volume
0.140896
Emergency Lumen Output (lm)
384
Wattage (W)
50
Colour Temperature (K)
4000
TP(a)/TP(b)
TP(a)
Minimum Order Quantity
1
Single Box Weight (kg)
5.287
Single box Height (mm)
1282
Single box Width (mm)
625
Single Box Depth (mm)
52
Single Box Volume
0.041665
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Order Unit
Unit
UOM For Battery Weight
KG
Lumen output (lm)
5750
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
Yes
Product Image
