Arial Multi Plus Emergency

Arial Plus Multi Backlit LED UGR<19 1200x600 White Panel in Emergency - 4000K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11791
Technical Specification
Volts (V)
220/240
Watts (W)
30/40/50/55/60
Colour Temp (K)
4000
Lumens (lm)
3600 (30W) / 4680 (40W) / 5770 (50W) / 6314 (55W) / 6782 (60W)
The Arial Plus Multi is our leading wattage switchable panel. With a high lumen output of up to 125 lumens per watt, this panel is ideal for areas that require high lux levels. The Arial Plus Multi can be installed in areas where TPa rated lighting products are essential, such as emergency exit routes including stairways and corridors.
Download Specification
Full Specification
Downloads
Name
Arial Plus Multi Backlit LED UGR<19 1200x600 White Panel in Emergency - 4000K
Volts (V)
220/240
Watts (W)
30/40/50/55/60
Colour Temp (K)
4000
Lumens (lm)
3600 (30W) / 4680 (40W) / 5770 (50W) / 6314 (55W) / 6782 (60W)
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP40
Height (mm)
1195
Width (mm)
595
Depth (mm)
25
Commodity Code
9405423990
EAN
5013588117911
Country Of Origin
CN
UNSPSC Code
39111544
Single Carton Height (mm)
1282
Single Carton Width (mm)
625
Single Carton Depth (mm)
52
Individual Volume
0.041665
Outer Box Height (mm)
1295
Outer Box Width (mm)
640
Outer Box Depth (mm)
170
Outer Box Qty
5
Outer Box Volume
0.140896
Individual Product Weight (kg)
3.815
Lumens per Watt (lm/W)
113-120
Product Category
LED Luminaires - Not Plastic
Outer Carton Barcode
1179100000005
Product Application
LED Panel
Emergency Lumen Output (lm)
384
Energy Consumption (kWh/1000h)
60
Unified Glare Rating
<19
LED Chip
Philips
Primary Material
Steel
Operating Temperature
0°C-35°C
Lumens Maintenance Ratio
L80 B10
Driver Manufacturer
BELL
TPa/TPb
TPa
Diffuser Material
Polycarbonate
Catalogue Page

Instructions

Photometric Data

Product Image
