Arial Plus Multi Backlit LED CCT UGR<19 600x600 White Panel

Code
11764
Next Delivery
17/11/2024 - 500 items
Technical Specification
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
3000/4000/6000
Dimmable?
No
Lumens (lm)
2400/3200/3600/4100
The Arial Plus Multi is our leading wattage switchable panel. With a high lumen output of up to 125 lumens per watt, this panel is ideal for areas that require high lux levels. The Arial Plus Multi can be installed in areas where TPa rated lighting products are essential, such as emergency exit routes including stairways and corridors.
Download Specification
Full Specification
Downloads
Name
Arial Plus Multi Backlit LED CCT UGR<19 600x600 White Panel
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
3000/4000/6000
Dimmable?
No
Lumens (lm)
2400/3200/3600/4100
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405409990
EAN
5013588117645
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
1.9
Single Carton Weight (KG)
2.5
Single Carton Height (mm)
670
Single Carton Width (mm)
627
Single Carton Depth (mm)
36
Individual Volume
0.01512324
Outer Box Weight (kg)
15.27
Outer Box Height (mm)
685
Outer Box Width (mm)
640
Outer Box Depth (mm)
250
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.1096
Lumens per Watt (lm/W)
113-123
