Arial Multi Plus

Arial Plus Multi Backlit 36W LED UGR<19 1200x300 White Panel with 1-10V Dimming - 4000K

Code
11776
Technical Specification
Volts (V)
220-240
Watts (W)
36
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
4100
The Arial Plus Multi is our leading wattage switchable panel. With a high lumen output of up to 125 lumens per watt, this panel is ideal for areas that require high lux levels. The Arial Plus Multi can be installed in areas where TPa rated lighting products are essential, such as emergency exit routes including stairways and corridors.
Full Specification
Downloads
Name
Arial Plus Multi Backlit 36W LED UGR<19 1200x300 White Panel with 1-10V Dimming - 4000K
Volts (V)
220-240
Watts (W)
36
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
4100
Life Hours
50,000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
1,195
Width (mm)
295
Depth (mm)
25
Commodity Code
9405409990
EAN
5013588117768
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
1.85
Single Carton Weight (KG)
2.4
Single Carton Height (mm)
1282
Single Carton Width (mm)
325
Single Carton Depth (mm)
36
Individual Volume
0.0149994
Outer Box Weight (kg)
14.5
Outer Box Height (mm)
1295
Outer Box Width (mm)
340
Outer Box Depth (mm)
250
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.110075
