Arial Multi Plus

Arial Plus Multi Backlit 60W LED UGR<19 1200x600 White Panel with 1-10V Dimming - 4000K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11793
Technical Specification
Volts (V)
220/240
Watts (W)
60
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
6750
The Arial Plus Multi is our leading wattage switchable panel. With a high lumen output of up to 125 lumens per watt, this panel is ideal for areas that require high lux levels. The Arial Plus Multi can be installed in areas where TPa rated lighting products are essential, such as emergency exit routes including stairways and corridors.
Download Specification
Full Specification
Downloads
Name
Arial Plus Multi Backlit 60W LED UGR<19 1200x600 White Panel with 1-10V Dimming - 4000K
Volts (V)
220/240
Watts (W)
60
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
6750
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
1195
Width (mm)
595
Depth (mm)
25
Commodity Code
9405409990
EAN
5013588117935
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
3.6
Single Carton Weight (KG)
4.8
Single Carton Height (mm)
1282
Single Carton Width (mm)
625
Single Carton Depth (mm)
36
Individual Volume
0.028845
Outer Box Weight (kg)
19.2
Outer Box Height (mm)
1295
Outer Box Width (mm)
640
Outer Box Depth (mm)
170
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.140896
Lumens per Watt (lm/W)
113
Catalogue Page

Instructions

Product Image
