Arial Multi Plus

Arial Plus Multi Backlit 36W LED Casambi Enabled UGR<19 600x600 White Panel - 4000K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11798
Technical Specification
Volts (V)
220/240
Watts (W)
36
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
4100
The Arial Plus Multi is our leading wattage switchable panel. With a high lumen output of up to 125 lumens per watt, this panel is ideal for areas that require high lux levels. The Arial Plus Multi can be installed in areas where TPa rated lighting products are essential, such as emergency exit routes including stairways and corridors.
Download Specification
Full Specification
Downloads
Name
Arial Plus Multi Backlit 36W LED Casambi Enabled UGR<19 600x600 White Panel - 4000K
Volts (V)
220/240
Watts (W)
36
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
4100
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405409990
EAN
5013588117980
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
1.7
Single Carton Weight (KG)
2.2
Single Carton Height (mm)
670
Single Carton Width (mm)
627
Single Carton Depth (mm)
36
Individual Volume
0.01512324
Outer Box Weight (kg)
13.5
Outer Box Height (mm)
685
Outer Box Width (mm)
640
Outer Box Depth (mm)
250
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.1096
Lumens per Watt (lm/W)
114
