Arial Multi Emergency

Arial Multi Backlit 36W LED CCT 600x600 Casambi Enabled White Panel in Emergency (1Y)

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11788
Technical Specification
Volts (V)
220/240
Watts (W)
36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
4897 (3000K) / 5461 (4000K) / 5023 (6000K)
One of the newest panels in the Arial Multi range, comes with a 7 year warranty and 2 year on site warranty as standard. This cost-effective lighting solution is available with a multitude of optional extras.
Download Specification
Full Specification
Downloads
Name
Arial Multi Backlit 36W LED CCT 600x600 Casambi Enabled White Panel in Emergency (1Y)
Volts (V)
220/240
Watts (W)
36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
4897 (3000K) / 5461 (4000K) / 5023 (6000K)
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405423990
EAN
5013588117881
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
2.687
Outer Box Qty
5
Lumens per Watt (lm/W)
136-152
Product Category
LED Luminaires - Not Plastic
Product Application
LED Panel
Inner Carton Barcode
5013588117881
Emergency Lumen Output (lm)
452
Energy Consumption (kWh/1000h)
36
Unified Glare Rating
<22
LED Chip
Philips
Primary Material
Steel
Operating Temperature
0°C-35°C
Lumens Maintenance Ratio
L80 B10
Driver Manufacturer
BELL
TPa/TPb
TPb
Diffuser Material
PMMA
Catalogue Page

Instructions

Product Image
