Arial Multi Standard

Arial Multi Backlit LED 600x600 White Panel - 4000K

Code
11740
Next Delivery
15/10/2024 - 2,996 items
Technical Specification
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
2300/2900/3250/3770
One of the newest panels in the Arial Multi range, comes with a 7 year warranty and 2 year on site warranty as standard. This cost-effective lighting solution is available with a multitude of optional extras.
Download Specification
Full Specification
Downloads
Name
Arial Multi Backlit LED 600x600 White Panel - 4000K
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
2300/2900/3250/3770
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405409990
EAN
5013588117409
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
1.5
Single Carton Weight (KG)
2
Single Carton Height (mm)
670
Single Carton Width (mm)
627
Single Carton Depth (mm)
36
Outer Box Weight (kg)
12.3
Outer Box Height (mm)
685
Outer Box Width (mm)
640
Outer Box Depth (mm)
250
Inner Box Qty
1
Individual Volume
0.01512
Outer Box Volume
0.1096
Outer Box Qty
4
Lumens per Watt (lm/W)
105-115
Catalogue Page

Instructions

Photometric Data

Product Image
