Arial T-Pro Multi Emergency

Arial T-Pro Multi LED CCT UGR<19 600x600 White Panel in Emergency (1Y)

This product is made to order, however we are out of stock of some components.
i
Please contact sales for accurate lead times for this item.
Code
11416
Technical Specification
Volts (V)
220/240
The Arial T-Pro Multi Backlit LED CCT Panel offers a unique twist on a standard LED panel. The contemporary slimline design and aesthetic light distribution works well in areas that would like to move away from the familiar style of panel we have all become accustomed to.
Download Specification
Full Specification
Downloads
Name
Arial T-Pro Multi LED CCT UGR<19 600x600 White Panel in Emergency (1Y)
Commodity Code
9405423990
EAN
5013588114163
Volts (V)
220/240
Individual Product Weight (kg)
2.5
Outer Box Weight (kg)
13
Outer Box Height (mm)
660
Outer Box Width (mm)
645
Outer Box Depth (mm)
250
Outer Box Qty
5
Outer Box Volume
0.106425
Life Hours
50000
Guarantee
7 Years
Height (mm)
595
Width (mm)
595
Depth (mm)
33
CRI (Ra)
85
IP Rating
IP20
Lumens per Watt (lm/W)
133-136 (In 4000K)
Unified Glare Rating
<19
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
36
Emergency Lumen Output (lm)
455
Wattage (W)
20/26/30/36
Colour Temperature (K)
3000/4000/6000
Minimum Order Quantity
1
Single Box Weight (kg)
3.25
Single box Height (mm)
645
Single box Width (mm)
632
Single Box Depth (mm)
55
Single Box Volume
0.0224202
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Panels
EDATA Product Range
Arial T-Pro
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
20W = 2649 (3000K), 2711 (4000K), 2684 (6000K) - 26W = 3393 (3000K), 3502 (4000K), 3428 (6000K) - 30W = 3880 (3000K), 4016 (4000K), 3906 (6000K) - 36W = 4614 (3000K), 4789 (4000K), 4614 (6000K)
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
Yes
