Arial T-Pro Multi

Arial T-Pro Multi 36W LED CCT UGR<19 600x600 White Panel with 1-10V Dimming

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11418
Technical Specification
Volts (V)
220/240
The Arial T-Pro Multi Backlit LED CCT Panel offers a unique twist on a standard LED panel. The contemporary slimline design and aesthetic light distribution works well in areas that would like to move away from the familiar style of panel we have all become accustomed to.
Download Specification
Full Specification
Downloads
Name
Arial T-Pro Multi 36W LED CCT UGR<19 600x600 White Panel with 1-10V Dimming
Commodity Code
9405423990
EAN
5013588114187
Volts (V)
220/240
Individual Product Weight (kg)
2.5
Outer Box Weight (kg)
13
Outer Box Height (mm)
660
Outer Box Width (mm)
645
Outer Box Depth (mm)
250
Outer Box Qty
4
Outer Box Volume
0.106425
CRI (Ra)
85
Guarantee
7 Years
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
33
Life Hours
50000
Frequency (Hz)
50/60
Lumens per Watt (lm/W)
128-133
Dimming Option
1-10V
Unified Glare Rating
<19
Energy Consumption (kWh/1000h)
36
Primary Material
Aluminium
Operating Temperature
0°C-35°C
Wattage (W)
36
Colour Temperature (K)
3000/4000/6000
TP(a)/TP(b)
TP(a)
Minimum Order Quantity
1
Single Box Weight (kg)
3.25
Single box Height (mm)
645
Single box Width (mm)
632
Single Box Depth (mm)
55
Single Box Volume
0.0224202
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Panels
EDATA Product Range
Arial T-Pro
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
4614 (3000K) / 4789 (4000K) / 4614 (6000K)
Dimmable
Yes
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
Yes
