Arial T-Pro Multi

Arial T-Pro Multi LED CCT UGR<19 600x600 White Panel

Code
11415
Technical Specification
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
When Set to 4000K - 2971 (20W) / 3880 (26W) / 4450 (30W) / 5278 (36W)
The Arial T-Pro Multi Backlit LED CCT Panel offers a unique twist on a standard LED panel. The contemporary slimline design and aesthetic light distribution works well in areas that would like to move away from the familiar style of panel we have all become accustomed to.
Download Specification
Full Specification
Downloads
Name
Arial T-Pro Multi LED CCT UGR<19 600x600 White Panel
Commodity Code
9405423990
EAN
5013588114156
Country Of Origin
CN
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
3000/4000/6000
Individual Product Weight (kg)
2.5
Single Carton Weight (KG)
3.25
Single Carton Height (mm)
645
Single Carton Width (mm)
632
Single Carton Depth (mm)
55
Individual Volume
0.0224202
Outer Box Weight (kg)
13
Outer Box Height (mm)
660
Outer Box Width (mm)
645
Outer Box Depth (mm)
250
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.106425
UNSPSC Code
39111544
CRI (Ra)
85
Guarantee
7 Years
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
33
Life Hours
50000
Frequency (Hz)
50/60
Lumens per Watt (lm/W)
146-149
EPREL Registration Number
1766679
Lumens (lm)
When Set to 4000K - 2971 (20W) / 3880 (26W) / 4450 (30W) / 5278 (36W)
Product Category
LED Luminaires - Not Plastic
Product Application
Commercial / Office
Unified Glare Rating
<19
Catalogue Page

Instructions

Photometric Data

Product Image
