Fitting
Mentor 32/42W LED 4ft CCT Batten with DALI Dimming
Code:
10287
To view product pricing and place orders, please log in to your account.
To view product pricing and place orders, please log in to your account.
The Mentor Wattage Switchable LED Integrated CCT Batten is colour switchable, with a choice of 3000K, 4000K, or 6000K, depending on the application. This is a 36-in-1 fitting with plug-in emergency packs, microwave and PIR sensors, and a DALI Dimming option available.
Specification
| Commodity Code | 9405423990 |
| EAN | 5013588102870 |
| Country Of Origin | CN |
| UNSPSC Code | 39111544 |
| Product Category | LED Luminaires - Not Plastic |
| Product Application | Schools / Colleges / Offices |
| Warranty | 7 Years (2 Years On Site) |
| Volts (V) | 220/240 |
| Life Hours | 50000 |
| CRI (Ra) | 80 |
| Switching Cycles | 25000 |
| Frequency (Hz) | 50/60 |
| Energy Consumption (kWh/1000h) | 53 |
| IP Rating | IP40 |
| Height (mm) | 97 |
| Length (mm) | 1200 |
| Individual Product Weight (kg) | 3.51 |
| Beam Angle | 115° |
| Lumens per Watt (lm/W) | 125-137 |
| Depth (mm) | 200 |
| Wattage (W) | 32/42 |
| Colour Temperature (K) | 3000/4000/5700 |
| Candelas | 1320-1690 |
| IK Rating | IK08 |
| Lumen output (lm) | 32W = 4093 (3000K) / 4351 (4000K) / 4398 (6000K) - 42W = 5247 (3000K) / 5577 (4000K) / 5619 (6000K) |
| Lumen Maintenance Ratio | L80 B10 |
| UNSPSC Code | 39111544 |
| Outer Box Qty | 2 |
| Height (mm) | 97 |
| Length (mm) | 1200 |
| Outer Box Height (mm) | 1525 |
| Outer Box Width (mm) | 220 |
| Outer Box Depth (mm) | 230 |
| Individual Product Weight (kg) | 3.51 |
| Outer Box Weight (kg) | 8.21 |
| Outer Box Volume | 0.07717 |
| Depth (mm) | 200 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 3.81 |
| Single box Height (mm) | 1510 |
| Single box Width (mm) | 205 |
| Single Box Depth (mm) | 105 |
| Single Box Volume | 0.0325 |
| Outer Box Barcode | 1028700000002 |
