Fitting
Cityline Rego 15/20/25/30W Street Light - 6m Flex - 3 Pin NEMA - Power-off Disconnector - CCT
Code:
72070
Please log in to see pricing
To view product pricing and place orders, please log in to your account.
The Cityline Rego brings sleek urban styling together with powerful, efficient LED performance for modern city landscapes.
Specification
| Product Category | LED Luminaires - Plastic |
| Product Application | Street Lighting |
| Country Of Origin | CN |
| Commodity Code | 9405423990 |
| EAN | 5063695041333 |
| UNSPSC Code | 39111608 |
| Warranty | 8 Years |
| Life Hours | 100000 |
| Volts (V) | 110/240 |
| Frequency (Hz) | 50/60 |
| Wattage (W) | 15/20/25/30 |
| Energy Consumption (kWh/1000h) | 30 |
| LED Drive Current | 230-280mA |
| Lumen output (lm) | 15W = 2505 (3000K) / 2745 (4000K) / 2670 (5000K) - 20W = 3180 (3000K) / 3580 (4000K) / 3400 (5000K) - 25W = 3750 (3000K) / 4350 (4000K) / 4025 (5000K) - 30W = 4350 (3000K) / 5130 (4000K) / 4620 (5000K) |
| Lumens per Watt (lm/W) | 145-183 |
| Colour Temperature (K) | 3000/4000/5000 |
| CRI (Ra) | 70 |
| Switching Cycles | 100000 |
| Height (mm) | 108 |
| Width (mm) | 174 |
| Length (mm) | 493 |
| IK Rating | IK08 |
| IP Rating | IP66 |
| Individual Product Weight (kg) | 5.12 |
| Lumen Maintenance Ratio | L80 B10 |
| Operating Temperature | -20℃ - +35℃ |
| Height (mm) | 108 |
| Width (mm) | 174 |
| Length (mm) | 493 |
| UNSPSC Code | 39111608 |
| Individual Product Weight (kg) | 5.12 |
| Minimum Order Quantity | 1 |
| Single box Height (mm) | 199 |
| Single box Width (mm) | 513 |
| Single Box Depth (mm) | 149 |
| Single Box Volume | 0.015210963 |
| Single Box Weight (kg) | 5.92 |
