Ultra Batten
Ultra 20W LED Integrated 4ft Single Batten - Casambi Dimming Enabled - 4000K
Code:
82098
The Ultra Batten is a versatile general-purpose luminaire. With a sleek look, this Ultra Batten is an ideal candidate for office, classroom and corridor installations.
To view product pricing and place orders, please log in to your account.
To view product pricing and place orders, please log in to your account.
Specification
| EAN | 5063695001313 |
| Country Of Origin | CN |
| Product Category | LED Luminaires - Not Plastic |
| Product Application | LED Batten |
| Commodity Code | 9405423990 |
| UNSPSC Code | 39111544 |
| Warranty | 7 Years |
| Volts (V) | 220/240 |
| Life Hours | 50000 |
| CRI (Ra) | 80 |
| Switching Cycles | 25000 |
| Frequency (Hz) | 50/60 |
| Beam Angle | 156° |
| Energy Consumption (kWh/1000h) | 20 |
| IP Rating | IP20 |
| Lumens per Watt (lm/W) | 183 |
| Operating Temperature | -30°C - +35°C |
| Wattage (W) | 20 |
| Equivalent Wattage (W) | 45 |
| Lumen Maintenance Ratio | 80 |
| Colour Temperature (K) | 4000 |
| Candelas | 650 |
| IK Rating | IK08 |
| Lumen output (lm) | 3664 |
| Height (mm) | 82 |
| Length (mm) | 1230 |
| UNSPSC Code | 39111544 |
| Individual Product Weight (kg) | 1.37 |
| Outer Box Weight (kg) | 10.07 |
| Outer Box Height (mm) | 1250 |
| Outer Box Width (mm) | 250 |
| Outer Box Depth (mm) | 210 |
| Outer Box Qty | 6 |
| Outer Box Volume | 0.06563 |
| Depth (mm) | 69 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 1.54 |
| Single box Height (mm) | 1240 |
| Single box Width (mm) | 90 |
| Single Box Depth (mm) | 75 |
| Single Box Volume | 0.00837 |
