Fitting
Illumina Muto V2 100/120/150/200W LED Switchable High Bay - 120° Lens - 4000K
Code:
08945V2
Please log in to see pricing
To view product pricing and place orders, please log in to your account.
The Illumina Muto is our most cost-effective LED High Bay to date.Perfect for all warehouses and factories of any size due to its wattage switchable functionality.
Specification
| Commodity Code | 9405423990 |
| EAN | 5013588900155 |
| Country Of Origin | CN |
| UNSPSC Code | 39111546 |
| Product Category | LED Luminaires - Not Plastic |
| Product Application | Commercial / Industrial / Warehousing |
| Warranty | 3 Years |
| Volts (V) | 220/240 |
| Life Hours | 30000 |
| Beam Angle | 120° |
| CRI (Ra) | 80 |
| Switching Cycles | 30000 |
| Frequency (Hz) | 50/60 |
| Energy Consumption (kWh/1000h) | 200 |
| IP Rating | IP65 |
| Height (mm) | 85 |
| Diameter (mm) | 312 |
| Individual Product Weight (kg) | 1.6 |
| LED Drive Current | 43mA |
| Lumens per Watt (lm/W) | 117 |
| Wattage (W) | 100/120/150/200 |
| Equivalent Wattage (W) | 150-400 |
| Colour Temperature (K) | 4000 |
| IK Rating | IK08 |
| Lumen output (lm) | 11735 (100W) - 14030 (120W) - 17537 (150W) - 23339 (200W) |
| Lumen Maintenance Ratio | L80 B10 |
| Operating Temperature | -20°C - +35°C |
| UNSPSC Code | 39111546 |
| Height (mm) | 85 |
| Diameter (mm) | 312 |
| Individual Product Weight (kg) | 1.6 |
| Outer Box Qty | 4 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 1.75 |
| Single box Height (mm) | 95 |
| Single box Width (mm) | 317 |
| Single Box Depth (mm) | 317 |
| Single Box Volume | 0.009546455 |
| Outer Box Barcode | 08945V2000004 |
| Outer Box Height (mm) | 345 |
| Outer Box Width (mm) | 333 |
| Outer Box Depth (mm) | 298 |
| Outer Box Volume | 0.03423573 |
