Fitting
Illumina Muto V2 100/120/150W LED Wattage Switchable High Bay - 120° Lens - 4000K
Code:
08946V2
To view product pricing and place orders, please log in to your account.
To view product pricing and place orders, please log in to your account.
The Illumina Muto is our most cost-effective LED High Bay to date.Perfect for all warehouses and factories of any size due to its wattage switchable functionality.
Specification
| Commodity Code | 9405423990 |
| EAN | 5013588001067 |
| Country Of Origin | CN |
| UNSPSC Code | 39111546 |
| Product Category | LED Luminaires - Not Plastic |
| Product Application | Commercial / Industrial / Warehousing |
| Warranty | 3 Years |
| Volts (V) | 220/240 |
| Life Hours | 30000 |
| Beam Angle | 120° |
| CRI (Ra) | 80 |
| Switching Cycles | 30000 |
| Frequency (Hz) | 50/60 |
| LED Drive Current | 48mA |
| Energy Consumption (kWh/1000h) | 150 |
| IP Rating | IP65 |
| Height (mm) | 85 |
| Diameter (mm) | 296 |
| Lumens per Watt (lm/W) | 111-120 |
| Individual Product Weight (kg) | 1.9 |
| Wattage (W) | 100/120/150 |
| Equivalent Wattage (W) | 150-300 |
| Colour Temperature (K) | 4000 |
| Candelas | 6142 |
| IK Rating | IK08 |
| Lumen output (lm) | 11975 (100W) - 13749 (120W) - 16696 (150W) |
| Lumen Maintenance Ratio | L80 B10 |
| Operating Temperature | -20°C - +35°C |
| Height (mm) | 85 |
| Diameter (mm) | 296 |
| UNSPSC Code | 39111546 |
| Outer Box Qty | 4 |
| Individual Product Weight (kg) | 1.9 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 2.05 |
| Outer Box Barcode | 08946V2000004 |
