Dura CCT V2
Dura 25/33/42/50W Wattage Switchable LED CCT V2 Anti-Corrosive 5ft Batten
Code:
10276V2
The Dura LED CCT Anti-Corrosive Batten is part of one of BELL's flagship luminaire families. This fitting takes the reliability of the Dura Batten and adds CCT & wattage switchable functionality.
To view product pricing and place orders, please log in to your account.
To view product pricing and place orders, please log in to your account.
Specification
| EAN | 5013588002811 |
| Country Of Origin | CN |
| Product Category | LED Luminaires - Plastic |
| Product Application | LED Batten |
| Commodity Code | 9405423100 |
| UNSPSC Code | 39111544 |
| Warranty | 7 Years (2 Years On Site) |
| Volts (V) | 220/240 |
| Life Hours | 50000 |
| Beam Angle | 120° |
| CRI (Ra) | 85 |
| Switching Cycles | 25000 |
| Frequency (Hz) | 50/60 |
| LED Drive Current | 90mA |
| Energy Consumption (kWh/1000h) | 50 |
| IP Rating | IP66 |
| Lumens per Watt (lm/W) | 141-162 |
| Operating Temperature | -30°C - +35°C |
| Wattage (W) | 25/33/42/50 |
| Lumen Maintenance Ratio | 80 |
| Colour Temperature (K) | 3000/4000/6000 |
| IK Rating | IK10 |
| Lumen output (lm) | 25W = 3840 (3000K) / 4043 (4000K & 6000K) - 33W = 4921 (3000K) / 5354 (4000K) / 5187 (6000K) - 42W = 6211 (3000K) / 6651 (4000K) / 6427 (6000K) - 50W = 7035 (3000K) / 7771 (4000K) / 7587 (6000K) |
| Height (mm) | 78 |
| Width (mm) | 96 |
| Length (mm) | 1570 |
| Diameter (mm) | 20 |
| Individual Product Weight (kg) | 1.7 |
| Outer Box Weight (kg) | 12.7 |
| Outer Box Height (mm) | 180 |
| Outer Box Width (mm) | 315 |
| Outer Box Depth (mm) | 1590 |
| Outer Box Qty | 6 |
| Outer Box Volume | 0.090153 |
| UNSPSC Code | 39111544 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 1.9 |
| Single box Height (mm) | 83 |
| Single box Width (mm) | 100 |
| Single Box Depth (mm) | 1575 |
| Single Box Volume | 0.0130725 |
| Outer Box Barcode | 10276V2000006 |
Optional Accessories
Code
Product Name
Unit Price
Quantity
Price
Code
10284
Product Name
Plug In Microwave Sensor for the Dura CCT V2 Battens with Dual On/Off & Corridor Dim Functionality
Unit Price
£0.00
Price
£0.00
Quantity
Login to see pricing
Code
10283
Product Name
Plug In Emergency Pack for the Dura LED CCT V2 Battens - Self Test On/Off
Unit Price
£0.00
Price
£0.00
Quantity
Login to see pricing
