Ultra V2 Batten
Ultra V2 20W LED Integrated 4ft Single Batten - 4000K
Code:
10200V2
The Ultra Batten is a versatile general-purpose luminaire. With a sleek look, this Ultra Batten is an ideal candidate for office, classroom and corridor installations.
To view product pricing and place orders, please log in to your account.
To view product pricing and place orders, please log in to your account.
Specification
| Commodity Code | 9405423990 |
| EAN | 5013588000701 |
| Country Of Origin | CN |
| UNSPSC Code | 39111544 |
| Product Category | LED Luminaires - Not Plastic |
| Product Application | LED Batten |
| Warranty | 7 Years (2 Years On Site) |
| Volts (V) | 220/240 |
| Life Hours | 50000 |
| Beam Angle | 120° |
| CRI (Ra) | 80 |
| Switching Cycles | 50000 |
| Frequency (Hz) | 50/60 |
| IP Rating | IP20 |
| LED Drive Current | 350mA |
| Energy Consumption (kWh/1000h) | 20 |
| Operating Temperature | -30°C - +35°C |
| Lumens per Watt (lm/W) | 173 |
| Wattage (W) | 20 |
| Lumen Maintenance Ratio | 80 |
| Colour Temperature (K) | 4000 |
| Candelas | 800 |
| IK Rating | IK08 |
| Lumen output (lm) | 3465 |
| UNSPSC Code | 39111544 |
| Height (mm) | 70 |
| Length (mm) | 1170 |
| Individual Product Weight (kg) | 1.25 |
| Outer Box Qty | 6 |
| Outer Box Width (mm) | 165 |
| Outer Box Height (mm) | 140 |
| Outer Box Depth (mm) | 1190 |
| Outer Box Weight (kg) | 8.1 |
| Depth (mm) | 61 |
| Outer Box Volume | 0.027489 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 1.45 |
| Single box Height (mm) | 75 |
| Single box Width (mm) | 65 |
| Single Box Depth (mm) | 1175 |
| Single Box Volume | 0.005728125 |
| Outer Box Barcode | 10200V2000004 |
