Arial Pro
Arial Pro 12/16/18/20W LED CCT IP44 Downlight in Emergency (5Y)
Code:
10958
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings.
To view product pricing and place orders, please log in to your account.
To view product pricing and place orders, please log in to your account.
Specification
| Commodity Code | 9405423100 |
| EAN | 5013588109589 |
| Country Of Origin | CN |
| UNSPSC Code | 39111515 |
| Product Category | LED Luminaires - Plastic |
| Product Application | LED Downlights |
| Warranty | 7 Years (5 Year Battery Warranty, 2 Years On Site) |
| Volts (V) | 220/240 |
| Life Hours | 50000 |
| Beam Angle | 90° |
| CRI (Ra) | 85 |
| Switching Cycles | 25000 |
| Frequency (Hz) | 50/60 |
| LED Drive Current | 500mA |
| Energy Consumption (kWh/1000h) | 20 |
| IP Rating | IP44 |
| Lumens per Watt (lm/W) | 129-144 |
| Operating Temperature | -5°C - +35°C |
| Emergency Lumen Output (lm) | 434 (3000K) / 483 (4000K) / 432 (6000K) |
| Wattage (W) | 12/16/18/20 |
| Emergency Wattage (W) | 3.4 |
| Lumen Maintenance Ratio | 80 |
| Colour Temperature (K) | 3000/4000/6000 |
| Lumen output (lm) | 12W = 1567 (3000K) / 1731 (4000K) / 1551 (6000K) - 16W = 2090 (3000K) / 2308 (4000K) / 2068 (6000K) - 18W = 2351 (3000K) / 2597 (4000K) / 2327 (6000K) - 20W = 2612 (3000K) / 2885 (4000K) / 2585 (6000K) |
| UNSPSC Code | 39111515 |
| Height (mm) | 117 |
| Diameter (mm) | 240 |
| Outer Box Height (mm) | 450 |
| Outer Box Width (mm) | 515 |
| Outer Box Depth (mm) | 515 |
| Outer Box Volume | 0.11935 |
| Outer Box Qty | 12 |
| Individual Product Weight (kg) | 1.747 |
| Minimum Order Quantity | 1 |
| Single Box Weight (kg) | 2.35 |
| Single box Height (mm) | 143 |
| Single box Width (mm) | 250 |
| Single Box Depth (mm) | 250 |
| Single Box Volume | 0.00894 |
| Outer Box Barcode | 1095800000012 |
