Arial Pro IP44

Arial Pro 10W LED CCT IP44 Downlight in Emergency (1Y)

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
10956
Technical Specification
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
3000/4000/6000
Dimmable?
No
Lumens (lm)
910
10W Arial Pro Downlight IP44 - Emergency (1 Year Battery Guarantee), CCT
Download Specification
Full Specification
Downloads
Name
Arial Pro 10W LED CCT IP44 Downlight in Emergency (1Y)
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
3000/4000/6000
Dimmable?
No
Lumens (lm)
910
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
230mA
Energy Consumption (kWh/1000h)
9
IP Rating
IP44
Downlight Cut Out (mm)
90-95
Commodity Code
9405409990
EAN
5013588109565
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00054
Height (mm)
70.5
Diameter (mm)
115
Outer Box Height (mm)
475
Outer Box Width (mm)
285
Outer Box Depth (mm)
525
Single Carton Weight (KG)
1.81
Single Carton Height (mm)
90
Single Carton Width (mm)
35
Single Carton Depth (mm)
170
Outer Box Volume
0.07107
Outer Box Qty
30
Individual Product Weight (kg)
1.382
Lumens per Watt (lm/W)
91
Inner Box Qty
1
Catalogue Page

Instructions

Photometric Data

Product Image
