Arial Multi CCT

Arial Multi Backlit LED CCT 600x600 White Panel with 1-10V Dimming

Code
11760
Technical Specification
Volts (V)
220/240
Watts (W)
36
Colour Temp (K)
3000/4000/6000
Dimmable?
Yes
Lumens (lm)
4450
One of the newest panels in the Arial Multi range, comes with a 7 year warranty and 2 year on site warranty as standard. This cost-effective lighting solution is available with a multitude of optional extras.
Full Specification
Downloads
Name
Arial Multi Backlit LED CCT 600x600 White Panel with 1-10V Dimming
Volts (V)
220/240
Watts (W)
36
Colour Temp (K)
3000/4000/6000
Dimmable?
Yes
Lumens (lm)
4450
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405409990
EAN
5013588117607
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
1.6
Single Carton Weight (KG)
2.25
Single Carton Height (mm)
670
Single Carton Width (mm)
627
Single Carton Depth (mm)
36
Individual Volume
0.01512
Outer Box Weight (kg)
13.5
Outer Box Height (mm)
685
Outer Box Width (mm)
640
Outer Box Depth (mm)
250
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.1096
Lumens per Watt (lm/W)
124
