Arial Multi CCT

Arial Multi Backlit LED CCT 600x600 White Panel

Code
11756
Next Delivery
09/03/2025 - 804 items
Technical Specification
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
20W = 2951 / 3110 / 2987 - 26W = 3702 / 3961 / 3738 - 30W = 4182 / 4510 / 4221 - 36W = 4897 / 5461 / 5023
One of the newest panels in the Arial Multi range, comes with a 7 year warranty and 2 year on site warranty as standard. This cost-effective lighting solution is available with a multitude of optional extras.
Full Specification
Downloads
Name
Arial Multi Backlit LED CCT 600x600 White Panel
Volts (V)
220/240
Watts (W)
20/26/30/36
Colour Temp (K)
3000/4000/6000
Lumens (lm)
20W = 2951 / 3110 / 2987 - 26W = 3702 / 3961 / 3738 - 30W = 4182 / 4510 / 4221 - 36W = 4897 / 5461 / 5023
Life Hours
50000
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405423990
EAN
5013588117560
Country Of Origin
CN
UNSPSC Code
39111544
Individual Product Weight (kg)
1.6
Single Carton Weight (KG)
2.25
Single Carton Height (mm)
670
Single Carton Width (mm)
627
Single Carton Depth (mm)
36
Individual Volume
0.01512
Outer Box Weight (kg)
13.5
Outer Box Height (mm)
655
Outer Box Width (mm)
718
Outer Box Depth (mm)
180
Inner Box Qty
1
Outer Box Qty
4
Outer Box Volume
0.0846522
Lumens per Watt (lm/W)
137-156
EPREL Registration Number
1766675
Product Category
LED Luminaires - Not Plastic
Product Application
LED Panel
Outer Carton Barcode
1175600000006
