Arial Pro IP65

Arial Pro 16W IP65 LED CCT Downlight with 1-10V Dimming

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
10969
Technical Specification
Volts (V)
220/240
Watts (W)
16
Colour Temp (K)
3000/4000/6000
Lumens (lm)
1600/1850/1600
Energy Rating
D
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings. With a 7 year guarantee across both the IP44 & IP65 range, the Arial Pro can be installed in a variety of applications with the confidence of knowing this product will stand the test of time.
Full Specification
Downloads
Name
Arial Pro 16W IP65 LED CCT Downlight with 1-10V Dimming
Volts (V)
220/240
Watts (W)
16
Colour Temp (K)
3000/4000/6000
Lumens (lm)
1600/1850/1600
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
400mA
Energy Consumption (kWh/1000h)
16
IP Rating
IP65
Downlight Cut Out (mm)
160-170
Commodity Code
9405409990
EAN
5013588109695
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00504
Height (mm)
102
Diameter (mm)
190
Outer Box Height (mm)
400
Outer Box Width (mm)
415
Outer Box Depth (mm)
415
Single Carton Weight (KG)
0.55
Single Carton Height (mm)
126
Single Carton Width (mm)
200
Single Carton Depth (mm)
200
Outer Box Weight (kg)
10
Outer Box Volume
0.06889
Outer Box Qty
12
Individual Product Weight (kg)
0.4
Lumens per Watt (lm/W)
100/116/100
Inner Box Qty
1
Equivalent Watts (W)
80
Energy Rating
D
Electric Class
2
Power Factor
>0.9
Driver Integral?
No
