Arial Pro IP65

Arial Pro 16W IP65 LED CCT Downlight with Dali Dimming

Code
10972
Technical Specification
Volts (V)
220/240
Watts (W)
16
Colour Temp (K)
3000/4000/6000
Lumens (lm)
2044 (3000K) / 2272 (4000K) / 2035 (6000K)
Energy Rating
D
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings. With a 7 year guarantee across both the IP44 & IP65 range, the Arial Pro can be installed in a variety of applications with the confidence of knowing this product will stand the test of time.
Download Specification
Full Specification
Downloads
Name
Arial Pro 16W IP65 LED CCT Downlight with Dali Dimming
Volts (V)
220/240
Watts (W)
16
Colour Temp (K)
3000/4000/6000
Lumens (lm)
2044 (3000K) / 2272 (4000K) / 2035 (6000K)
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
400mA
Energy Consumption (kWh/1000h)
16
IP Rating
IP65
Downlight Cut Out (mm)
160-170
Commodity Code
9405423100
EAN
5013588109725
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00504
Outer Box Qty
12
Height (mm)
102
Diameter (mm)
190
Outer Box Height (mm)
400
Outer Box Width (mm)
415
Outer Box Depth (mm)
415
Single Carton Weight (KG)
0.55
Single Carton Height (mm)
126
Single Carton Width (mm)
200
Single Carton Depth (mm)
200
Outer Box Weight (kg)
10
Outer Box Volume
0.06889
Individual Product Weight (kg)
0.4
Lumens per Watt (lm/W)
127-142
Equivalent Watts (W)
80
Energy Rating
D
Electric Class
2
Power Factor
>0.9
Driver Integral?
No
Dimming Option
Dali
Product Category
LED Luminaires - Plastic
Outer Carton Barcode
1097200000012
Product Application
LED Downlight
