Arial Pro IP65

Arial Pro 20W IP65 LED CCT Downlight with Dali Dimming

Code
10973
Technical Specification
Volts (V)
220-240
Watts (W)
20
Colour Temp (K)
3000/4000/6000
Dimmable?
Yes
Lumens (lm)
2250
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings. With a 7 year guarantee across both the IP44 & IP65 range, the Arial Pro can be installed in a variety of applications with the confidence of knowing this product will stand the test of time.
Full Specification
Downloads
Name
Arial Pro 20W IP65 LED CCT Downlight with Dali Dimming
Volts (V)
220-240
Watts (W)
20
Colour Temp (K)
3000/4000/6000
Dimmable?
Yes
Lumens (lm)
2250
Life Hours
50,000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
500
Energy Consumption (kWh/1000h)
20
IP Rating
IP65
Downlight Cut Out (mm)
200-210
Commodity Code
9405409990
EAN
5013588109732
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00894
Outer Box Qty
12
Height (mm)
117
Diameter (mm)
240
Outer Box Height (mm)
475
Outer Box Width (mm)
515
Outer Box Depth (mm)
515
Single Carton Weight (KG)
0.85
Single Carton Height (mm)
143
Single Carton Width (mm)
250
Single Carton Depth (mm)
250
Inner Box Height (mm)
143
Inner Box Width (mm)
250
Inner Box Depth (mm)
250
Outer Box Weight (kg)
10.5
Outer Box Volume
0.12598
Inner Box Volume
0.00894
