Arial Pro IP65

Arial Pro 10W IP65 LED CCT Downlight with Dali Dimming

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
10971
Technical Specification
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
3000/4000/6000
Lumens (lm)
950/1050/1000
Energy Rating
E
10W Arial Pro Downlight IP65 - Dali Dim, CCT
Download Specification
Full Specification
Downloads
Name
Arial Pro 10W IP65 LED CCT Downlight with Dali Dimming
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
3000/4000/6000
Lumens (lm)
950/1050/1000
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
230mA
Energy Consumption (kWh/1000h)
10
IP Rating
IP65
Downlight Cut Out (mm)
90-95
Commodity Code
9405423100
EAN
5013588109718
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00207
Outer Box Qty
30
Height (mm)
71
Diameter (mm)
115
Outer Box Width (mm)
285
Outer Box Depth (mm)
525
Single Carton Weight (KG)
0.275
Single Carton Height (mm)
90
Single Carton Width (mm)
135
Single Carton Depth (mm)
170
Outer Box Weight (kg)
9.5
Individual Product Weight (kg)
0.195
Lumens per Watt (lm/W)
95/105/100
Inner Box Qty
1
Equivalent Watts (W)
50
Energy Rating
E
Electric Class
2
Power Factor
>0.9
Driver Integral?
No
Outer Box Height (mm)
475
Outer Box Volume
0.071071875
Dimming Option
Dali
Product Category
LED Luminaires - Plastic
Catalogue Page

Instructions

Product Image
