Arial Pro IP65

Arial Pro 10W IP65 LED CCT Downlight with Dali Dimming

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
10971
Technical Specification
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
3000/4000/6000
Dimmable?
Yes
Lumens (lm)
910
10W Arial Pro Downlight IP65 - Dali Dim, CCT
Download Specification
Full Specification
Downloads
Name
Arial Pro 10W IP65 LED CCT Downlight with Dali Dimming
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
3000/4000/6000
Dimmable?
Yes
Lumens (lm)
910
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
230mA
Energy Consumption (kWh/1000h)
9
IP Rating
IP65
Downlight Cut Out (mm)
90-95
Commodity Code
9405409990
EAN
5013588109718
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00207
Outer Box Qty
30
Height (mm)
70.5
Diameter (mm)
115
Outer Box Width (mm)
285
Outer Box Depth (mm)
525
Single Carton Weight (KG)
0.31
Single Carton Height (mm)
90
Single Carton Width (mm)
135
Single Carton Depth (mm)
170
Outer Box Weight (kg)
9.5
Individual Product Weight (kg)
0.195
Lumens per Watt (lm/W)
91
Inner Box Qty
1
Catalogue Page

Instructions

Product Image
