Arial Pro IP44

Arial Pro 16W IP44 LED CCT Downlight

Code
10951
Next Delivery
05/02/2025 - 300 items
Technical Specification
Volts (V)
220/240
Watts (W)
16
Colour Temp (K)
3000/4000/6000
Lumens (lm)
1660
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings. With a 7 year guarantee across both the IP44 & IP65 range, the Arial Pro can be installed in a variety of applications with the confidence of knowing this product will stand the test of time.
Download Specification
Full Specification
Downloads
Name
Arial Pro 16W IP44 LED CCT Downlight
Volts (V)
220/240
Watts (W)
16
Colour Temp (K)
3000/4000/6000
Lumens (lm)
1660
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
400mA
Energy Consumption (kWh/1000h)
16
IP Rating
IP44
Downlight Cut Out (mm)
160-170
Commodity Code
9405409990
EAN
5013588109510
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00504
Height (mm)
102
Diameter (mm)
190
Outer Box Height (mm)
400
Outer Box Width (mm)
415
Outer Box Depth (mm)
415
Single Carton Weight (KG)
0.55
Single Carton Height (mm)
126
Single Carton Width (mm)
200
Single Carton Depth (mm)
200
Individual Product Weight (kg)
0.4
Outer Box Weight (kg)
10
Inner Box Qty
1
Outer Box Volume
0.06889
Outer Box Qty
12
Lumens per Watt (lm/W)
104
Catalogue Page

Instructions

Photometric Data

Product Image
