Arial Pro IP44

Arial Pro 20W IP44 LED CCT Downlight

Code
10952
Next Delivery
10/02/2025 - 2,004 items
Technical Specification
Volts (V)
220/240
Watts (W)
20
Colour Temp (K)
3000/4000/6000
Lumens (lm)
2250
The Arial Pro LED Downlight is a sleek looking luminaire designed to replace cumbersome CFL fittings. With a 7 year guarantee across both the IP44 & IP65 range, the Arial Pro can be installed in a variety of applications with the confidence of knowing this product will stand the test of time.
Download Specification
Full Specification
Downloads
Name
Arial Pro 20W IP44 LED CCT Downlight
Volts (V)
220/240
Watts (W)
20
Colour Temp (K)
3000/4000/6000
Lumens (lm)
2250
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
500mA
Energy Consumption (kWh/1000h)
20
IP Rating
IP44
Downlight Cut Out (mm)
200-210
Commodity Code
9405423100
EAN
5013588109527
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00894
Outer Box Qty
12
Height (mm)
117
Diameter (mm)
240
Outer Box Height (mm)
475
Outer Box Width (mm)
515
Outer Box Depth (mm)
515
Single Carton Weight (KG)
0.75
Single Carton Height (mm)
143
Single Carton Width (mm)
250
Single Carton Depth (mm)
250
Individual Product Weight (kg)
0.56
Outer Box Weight (kg)
10.5
Inner Box Qty
1
Outer Box Volume
0.12598
Lumens per Watt (lm/W)
113
Product Category
LED Luminaires - Plastic
Catalogue Page

Instructions

Photometric Data

Product Image
