Arial Pro IP44

Arial Pro 10W IP44 LED CCT Downlight with Dali Dimming

Code
10962
Technical Specification
Volts (V)
220/240
Colour Temp (K)
3000/4000/6000
Watts (W)
10
Lumens (lm)
1209 (3000K) / 1309 (4000K) / 1243 (6000K)
10W Arial Pro Downlight IP44 - Dali Dim, CCT
Download Specification
Full Specification
Downloads
Name
Arial Pro 10W IP44 LED CCT Downlight with Dali Dimming
Volts (V)
220/240
Colour Temp (K)
3000/4000/6000
Life Hours
50000
Beam Angle
90°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
230mA
Energy Consumption (kWh/1000h)
10
IP Rating
IP44
Downlight Cut Out (mm)
90
Commodity Code
9405423100
EAN
5013588109626
Country Of Origin
CN
UNSPSC Code
39111515
Individual Volume
0.00207
Outer Box Qty
30
Height (mm)
71
Diameter (mm)
115
Outer Box Width (mm)
285
Outer Box Depth (mm)
525
Single Carton Weight (KG)
0.275
Single Carton Height (mm)
90
Single Carton Width (mm)
135
Single Carton Depth (mm)
170
Outer Box Weight (kg)
9.5
Individual Product Weight (kg)
0.195
Equivalent Watts (W)
50
Electric Class
Class II
Power Factor
>0.9
Driver Integral?
No
Outer Box Height (mm)
475
Outer Box Volume
0.071071875
Dimming Option
Dali
Product Category
LED Luminaires - Plastic
Outer Carton Barcode
1096200000030
Product Application
LED Downlight
Minimum Order Quantity
1
Single Box Packaging Weight (kg)
0.08
Operating Temperature
-5°C - +35°C
Lumens Maintenance Ratio
L80 B10
Watts (W)
10
Lumens (lm)
1209 (3000K) / 1309 (4000K) / 1243 (6000K)
Lumens per Watt (lm/W)
121-131
