Skyline Slim+ Asymmetric

Skyline Slim+ 70W LED Asymmetric Floodlight - 4000K

Code
10996
Technical Specification
Volts (V)
240
Watts (W)
70
Colour Temp (K)
4000
Lumens (lm)
8400
The Skyline Slim+ LED Floodlight is suitable for a wide range of applications. Available in a vast range of wattages, this low energy floodlight is ideal for any lighting project, big or small.
Download Specification
Full Specification
Downloads
Name
Skyline Slim+ 70W LED Asymmetric Floodlight - 4000K
Volts (V)
240
Watts (W)
70
Colour Temp (K)
4000
Lumens (lm)
8400
Equivalent Watts (W)
100
Life Hours
50000
Beam Angle
110°
CRI (Ra)
80
Guarantee
5 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
715mA
Energy Consumption (kWh/1000h)
70
IP Rating
IP65
Height (mm)
259
Width (mm)
229
Depth (mm)
48
Commodity Code
9405423990
EAN
5013588109961
Country Of Origin
CN
UNSPSC Code
39111626
Single Carton Height (mm)
280
Single Carton Width (mm)
70
Single Carton Depth (mm)
323
Individual Volume
0.00633
Outer Box Height (mm)
292
Outer Box Width (mm)
284
Outer Box Depth (mm)
329
Outer Box Qty
4
Individual Product Weight (kg)
3.096
Single Carton Weight (KG)
3.28437
Outer Box Weight (kg)
13.6759
Outer Box Volume
0.02728
Impact Protection
IK8
Lumens per Watt (lm/W)
120
Flex
1m
Windage
0.074m²
Power Factor
>0.9
Product Category
LED Luminaires - Not Plastic
Product Application
Exterior Lighting
LED Chip
Phillips
Operating Temperature
-20°C to +25°C
Lumens Maintenance Ratio
80
Catalogue Page

Instructions

Photometric Data

Product Image
