Dura Single

Dura 10W LED Anti-Corrosive 2ft Single Batten - 4000K

Code
10257
Technical Specification
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
1260
Energy Rating
E
10W Dura LED Anti Corrosive Batten - 4000K, Single 600mm (2ft)
Download Specification
Full Specification
Downloads
Name
Dura 10W LED Anti-Corrosive 2ft Single Batten - 4000K
Volts (V)
220/240
Watts (W)
10
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
1260
Life Hours
50000
Beam Angle
130°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
240mA
Energy Consumption (kWh/1000h)
10
IP Rating
IP66
Commodity Code
9405409990
EAN
5013588102573
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.0066
Outer Box Qty
12
Height (mm)
90
Width (mm)
90
Length (mm)
654
Outer Box Height (mm)
690
Outer Box Width (mm)
310
Outer Box Depth (mm)
420
Candelas (cd)
340
Equivalent Watts (W)
20
Single Carton Height (mm)
660
Single Carton Width (mm)
100
Single Carton Depth (mm)
100
Individual Product Weight (kg)
0.89
Single Carton Weight (KG)
1.04
Outer Box Weight (kg)
13.86
Plastic Packaging Weight (kg)
0.01
Outer Box Volume
0.08984
Impact Protection
IK10
Energy Rating
E
Lumens per Watt (lm/W)
126
Inner Box Qty
1
Power Factor
0.96kW
Electric Class
1
Driver Integral?
Yes
Catalogue Page

Instructions

Photometric Data

Product Image
