Dura Single

Dura 25W LED Anti-Corrosive 5ft Single Batten in Emergency with Microwave Sensor - 4000K

Code
06715
Next Delivery
18/10/2024 - 196 items
Technical Specification
Volts (V)
220/240
Watts (W)
25
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
3430
Energy Rating
E
The Dura LED Anti Corrosive Batten is one of BELL’s flagship Luminaires. This fully enclosed luminaire comes with stainless steel diffuser clips, ideal for exterior lighting projects that are open to the elements.
Download Specification
Full Specification
Downloads
Name
Dura 25W LED Anti-Corrosive 5ft Single Batten in Emergency with Microwave Sensor - 4000K
Volts (V)
220/240
Watts (W)
25
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
3430
Life Hours
50000
Beam Angle
137°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
600mA
Energy Consumption (kWh/1000h)
25
IP Rating
IP66
Commodity Code
9405409990
EAN
5013588067155
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.0157
Outer Box Qty
4
Height (mm)
90
Width (mm)
90
Length (mm)
1530
Outer Box Height (mm)
1610
Outer Box Width (mm)
210
Outer Box Depth (mm)
220
Candelas (cd)
900
Equivalent Watts (W)
55
Single Carton Height (mm)
1570
Single Carton Width (mm)
100
Single Carton Depth (mm)
100
Individual Product Weight (kg)
2.19
Single Carton Weight (KG)
2.46
Outer Box Weight (kg)
10.88
Plastic Packaging Weight (kg)
0.02
Outer Box Volume
0.07438
Impact Protection
IK10
Energy Rating
E
Lumens per Watt (lm/W)
137
Inner Box Qty
1
Electric Class
1
Power Factor
0.97kW
Driver Integral?
Yes
