Dura Single

Dura 25W LED Anti-Corrosive 5ft Single Batten with Microwave Sensor & Corridor Dim Function - 4000K

Code
06712
Technical Specification
Volts (V)
220/240
Watts (W)
25
Colour Temp (K)
4000
Lumens (lm)
4224
Energy Rating
E
The Dura LED Anti Corrosive Batten is one of BELL’s flagship luminaires. This fully enclosed luminaire comes with stainless steel diffuser clips, ideal for exterior lighting projects that are open to the elements.
Download Specification
Full Specification
Downloads
Name
Dura 25W LED Anti-Corrosive 5ft Single Batten with Microwave Sensor & Corridor Dim Function - 4000K
Volts (V)
220/240
Watts (W)
25
Colour Temp (K)
4000
Lumens (lm)
4224
Life Hours
50000
Beam Angle
137°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
540mA
Energy Consumption (kWh/1000h)
25
IP Rating
IP66
Commodity Code
9405409990
EAN
5013588067124
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.0157
Outer Box Qty
4
Height (mm)
90
Width (mm)
90
Length (mm)
1530
Outer Box Height (mm)
1610
Outer Box Width (mm)
210
Outer Box Depth (mm)
220
Candelas (cd)
900
Equivalent Watts (W)
55
Single Carton Height (mm)
1570
Single Carton Width (mm)
100
Single Carton Depth (mm)
100
Individual Product Weight (kg)
2.02
Single Carton Weight (KG)
2.29
Outer Box Weight (kg)
10.28
Plastic Packaging Weight (kg)
0.02
Outer Box Volume
0.07438
Impact Protection
IK10
Energy Rating
E
Lumens per Watt (lm/W)
169
Inner Box Qty
1
Power Factor
0.97kW
Electric Class
1
Driver Integral?
Yes
