Ultra Double

Ultra 40W LED Integrated 4ft Double Batten - 4000K

Code
10206
Technical Specification
Volts (V)
220/240
Watts (W)
40
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
5360
Energy Rating
E
40W Ultra LED Integrated Batten - 4000K, Double 1230mm (4ft)
Download Specification
Full Specification
Downloads
Name
Ultra 40W LED Integrated 4ft Double Batten - 4000K
Volts (V)
220/240
Watts (W)
40
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
5360
Life Hours
50000
Beam Angle
128°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
1080mA
Energy Consumption (kWh/1000h)
40
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102061
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01212
Outer Box Qty
6
Height (mm)
82
Width (mm)
109
Length (mm)
1230
Outer Box Height (mm)
260
Outer Box Width (mm)
290
Outer Box Depth (mm)
1250
Candelas (cd)
1400
Equivalent Watts (W)
90
Single Carton Height (mm)
86
Single Carton Width (mm)
114
Single Carton Depth (mm)
1236
Outer Box Volume
0.09425
Individual Product Weight (kg)
1.89
Single Carton Weight (KG)
2.06
Outer Box Weight (kg)
13.62
Plastic Packaging Weight (kg)
0.01
Inner Box Qty
1
Energy Rating
E
Lumens per Watt (lm/W)
134
Electric Class
1
Driver Integral?
Yes
Power Factor
0.96kW
