Ultra Double

40W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1230mm (4ft)

Code
10211
Technical Specification
Volts (V)
220-240
Watts (W)
40
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
5360
40W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1230mm (4ft)
Download Specification
Full Specification
Name
40W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1230mm (4ft)
Volts (V)
220-240
Watts (W)
40
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
5360
Life Hours
50,000
Beam Angle
128°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
1,080
Energy Consumption (kWh/1000h)
40
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102115
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01339
Outer Box Qty
6
Height (mm)
82
Width (mm)
109
Length (mm)
1,230
Outer Box Height (mm)
1250
Outer Box Width (mm)
285
Outer Box Depth (mm)
260
Candelas (cd)
1,400
Equivalent Watts (W)
90
Single Carton Height (mm)
1240
Single Carton Width (mm)
120
Single Carton Depth (mm)
90
Individual Product Weight (kg)
2.17
Single Carton Weight (KG)
2.34
Outer Box Weight (kg)
15.3
Plastic Packaging Weight (kg)
0.01
Outer Box Volume
0.09263
