Ultra Double

60W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1530mm (5ft)

Code
10223
Technical Specification
Volts (V)
220-240
Watts (W)
60
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
7600
60W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1530mm (5ft)
Download Specification
Full Specification
Name
60W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1530mm (5ft)
Volts (V)
220-240
Watts (W)
60
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
7600
Life Hours
50,000
Beam Angle
128°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
1,440
Energy Consumption (kWh/1000h)
60
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102238
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01506
Outer Box Qty
4
Height (mm)
82
Width (mm)
109
Length (mm)
1,530
Outer Box Height (mm)
250
Outer Box Width (mm)
210
Outer Box Depth (mm)
155
Candelas (cd)
2,000
Equivalent Watts (W)
125
Single Carton Height (mm)
86
Single Carton Width (mm)
114
Single Carton Depth (mm)
1536
Outer Box Volume
0.00814
No additional downloads available
