Ultra Double

60W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor + Corridor Dim Function 1530mm (5ft)

Code
10222
Technical Specification
Volts (V)
220-240
Watts (W)
60
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
7600
60W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor + Corridor Dim Function 1530mm (5ft)
Download Specification
Full Specification
Downloads
Name
60W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor + Corridor Dim Function 1530mm (5ft)
Volts (V)
220-240
Watts (W)
60
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
7600
Life Hours
50,000
Beam Angle
128°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
1,440
Energy Consumption (kWh/1000h)
60
IP Rating
IP20
Commodity Code
94054099
EAN
5013588102221
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01506
Outer Box Qty
10
Outer Box CMB
0.08
Height (mm)
82
Width (mm)
109
Length (mm)
1,530
Outer Box Height (mm)
1555
Outer Box Width (mm)
250
Outer Box Depth (mm)
210
Candelas (cd)
2,000
Equivalent Watts (W)
125
Single Carton Height (mm)
1540
Single Carton Width (mm)
120
Single Carton Depth (mm)
90
Individual Product Weight (kg)
2.45
Single Carton Weight (KG)
2.85
Outer Box Weight (kg)
11.79
Plastic Packaging Weight (kg)
0.02
