Ultra Double

Ultra 80W LED Integrated 6ft (1795mm) Double Batten in Emergency with Microwave Sensor & Corridor Dim Function - 4000K

Code
10235
Technical Specification
Volts (V)
220-240
Watts (W)
80
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
10600
80W Ultra LED Integrated Batten - 4000K, Double Emergency with Microwave Sensor + Corridor Dim Function 1795mm (6ft)
Full Specification
Downloads
Name
Ultra 80W LED Integrated 6ft (1795mm) Double Batten in Emergency with Microwave Sensor & Corridor Dim Function - 4000K
Volts (V)
220-240
Watts (W)
80
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
10600
Life Hours
50,000
Beam Angle
134°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
840
Energy Consumption (kWh/1000h)
80
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102351
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.019494
Outer Box Qty
4
Height (mm)
82
Width (mm)
109
Length (mm)
1,795
Outer Box Height (mm)
1820
Outer Box Width (mm)
250
Outer Box Depth (mm)
210
Candelas (cd)
2,850
Equivalent Watts (W)
165
Single Carton Height (mm)
1805
Single Carton Width (mm)
120
Single Carton Depth (mm)
90
Outer Box Volume
0.09555
Individual Product Weight (kg)
3.07
Single Carton Weight (KG)
3.39
Outer Box Weight (kg)
14.88
Plastic Packaging Weight (kg)
0.02
